This page on our website, is used to show the various custom mechanical optical components that have been manufactured at Xactra Technologies.  As you can see, we have produced a wide variety of optical components used in every possible application.   New images will be added periodically.  Please stop back to see what is new at Xactra.






Lens Assembly of multiple components. Satin matt anodize.Lens Housing with satin matt andodize and laser engraving.Lens Housing and related retainers. All parts made from 20% glass filled Ultem thermoplastic.Zoom Lens Housing. Light blue anodize.Lens Housing with satin matt anodize.Lens Housing finished in a blue/gray anodize.Lens Housing in stainless steel.
Each photo in our Component Gallery can be made larger by clicking on the image.  Start at the first image in the row. You can then scroll through that entire row once the image opens.
Various components from our Milling Department.
Lens Housing - Satin Matt anodize.Lens Housing - Satin Matt anodize.Lens Housing - Standard anodize.Lens Housing - Standard anodize.Lens Housing - Two color anodize.Lens housing for nigh vision goggles.Lens Housing - Made in one piece and one set up using a 5 axis Mill/Turn machine.
Lens Housing with Satin Matt anodize.Lens Housing with Satin Matt anodize.Lens Assembly of two pieces. Standard anodize and chem film.Lens Assembly of multiple components. Standard anodize.Lens Housing with Satin Matt anodize.Zoom Lens Housing. Standard anodize and chem film.Lens Housing with standard anodize.
Various Lens Housings and Assemblies
Large Zoom System and Related Components
Main Housing – 7” (177.8mm) Diameter, 9” (228.6mm) long. Parallelism of rail mounting surfaces - .0004 (0.010mm) across a 4” (101.6mm) span.Cam HousingPerpendicularity of rail mounting surface to lens seat - .0004 (0.010mm)Perpendicularity of rail mounting surface to lens seat - .0004 (0.010mm)Perpendicularity of rail mounting surface to lens seat - .0004 (0.010mm)
Main Housing – 4” (101.6mm) Diameter, 5” (127mm) long. Inside Diameter tolerance +/- .0002 (.0051mm) for fit to 4 separate internal lens mounts.Main Housing – 4” (101.6mm) Diameter, 5” (127mm) long. Inside Diameter tolerance +/- .0002 (.0051mm) for fit to 4 separate internal lens mounts.Teflon Anodize.
Small Zoom System and Related Components
Various Mirror Blanks produced at Xactra. We produce various custom configurations of mirror blanks that our customers diamond turn. The component in the center shows an example that has been diamond turned as a finished mirror.Mirror blank made by Xactra, and supplied as a plated component. Picture shows a finished diamond turned mirror.
Mirror Blanks
Thermal Weapon Sight (TWS) Urban Gray anodize, chem film and standard black anodize.
Thermal Weapon Sight
